Model: IPS-24-22

NewMar IPS 24-22 Integrated Power Supply
$2,073.00
Contact Information

NewMar

NewMar IPS 24-22 Integrated Power Supply

A unique, multifunction power supply, the NewMar IPS 24-22 Integrated Power Supply houses a built-in battery back-up and several power accessories all in a single 2 RU chassis. It's ideal for any low to medium AC fault tolerant power applications, and terminals are provided so you can easily add a parallel rectifier, if needed.
Contact us today for a free consultation!

Specifications
  • Input Amps @ Full Load 115/230: 11/5.5
  • VDC: 27.2
  • Output Adjustment Range: 20 - 30 VDC
  • Internal Battery Capacity: 10 A-H
  • Ground Reference: Negative

Related Material

NewMar IPS 24-22 Integrated Power Supply Manual
NewMar Online Catalog



The NewMar IPS 24-22 Integrated Power Supply features front panel monitors for L.E.D, status, and digital ammeter/voltmeter. If AC fails, built-in back-up batteries instantly take over with no transfer delay or interruption. Whenever AC is restored, batteries will then instantly recharge, and a manual battery disconnect switch lets you perform battery maintenance while the system is still operating.

NewMar IPS 24-22 Integrated Power Supply

NewMar IPS-24-22 Features
  • For 24 volt systems.
  • Built-in battery instantly takes over to power the load during AC failure.
  • No transfer delays or interruptions when switching from failed battery.
  • Anodized aluminum case.
  • Forced air cooling.
  • 19" or 23", 6" forward rackmount brackets included.
  • Pre-wired Form C alarm contacts.

Power Supply Protection Features
  • Short circuit, current limit.
  • Overvoltage.
  • Input Fuse & Circuit Breaker
  • Adjustable low voltage or manual battery disconnect.
  • Automatic thermal shutdown & recovery.
  • Circuit breaker for internal back-up battery.
A unique, multifunction power supply, the NewMar IPS 24-22 Integrated Power Supply houses a built-in battery back-up and several power accessories all in a single 2 RU chassis. It's ideal for any low to medium AC fault tolerant power applications, and terminals are provided so you can easily add a parallel rectifier, if needed. Contact us today for a free consultation! Specifications Input Amps @ Full Load 115/230: 11/5.5 VDC: 27.2 ...
[Show More]


Contact us today for a free consultation!

NewMar IPS 24-22 Integrated Power Supply Manual

NewMar Online Catalog

This product was added to our catalog on Monday 22 February, 2021.
